Fixed Aerosol Fire Extinguishing Systems Protecting Lives and
Assets
The General Index For Fixed Aerosol Fire Extinguishing Systems
1. FireLess aerosol extinguishing agent is many times more
effective than gaseous or other conventional extinguishing agents.
It only need a small amount to extinguish fires. It is green and
environmental.
2. Class A, B, C, E fires can be extinguished very quickly with
seconds by total flooding ways
3. Multiple starting mode, besides electric start, it also can be
started by FireLess HD mechanical temperature induction starting
device. Independently detection and starting.
4. No piping needed, modular and compact design is very convenient
for replacing items.
5. Long service life and low cost of maintenance, don’t need to
care it much.
6. Easily to install and use
The basic information
| Product model | FireLess 35 | FireLess 50 | FireLess 100 |
| Overall dimension | 240(diameter)X57(height) | 240(diameter)X69(height) | 240(diameter)X110(height) |
| Weight of device | 2.9kg | 3.4kg | 5.3kg |
| Agent quantity | 1.0kg | 1.4kg | 2.8kg |
| Protected volume | 35m3 | 50m3 | 100m3 |
| Activation method | Electric start | Electric start | Electric start |
| Operation condition | -50℃~+95℃ | -50℃~+95℃ | -50℃~+95℃ |
| Discharge time | ≤7s | ≤9s | ≤15s |
| Start current (mA, DC) | ≥700 | ≥700 | ≥700 |
| Safe current (mA, DC) | ≤150 | ≤150 | ≤150 |
| Working temperature | -50℃~+95℃ | -50℃~+95℃ | -50℃~+95℃ |
| Service life | 10 years | 10 years | 10 years |
| Installation type | Fixed | Fixed | Fixed |
| Original place | China | China | China |
The compatibility of FireLess series products
The Product compatibility is excellent. The compatibility is mainly
displayed through the environmental test to analyze the
compatibility of components such as aerosol fire extinguishing
agent and liner and ignition head, as well as the compatibility of
the device and the application environment.
FireLess series products have passed high and low temperature
environmental test, vibration environment test, high humidity
environment test and electromagnetic compatibility environment
test. The overall appearance and performance did not change
significantly. The aerosol fire extinguishing agent column, liner,
outer casing, electric ignition head, electric ignition lead,
thermal line and other components did not change. there is no
incompatibility is shown in the device itself and in the
application environment.
Because of distinguished advantages FireLess series products have,
they will be a good guard for protecting your target objects from
fires.
