Fixed Aerosol Fire Extinguishing Systems For Electrical Fires Class
C Fires
Technical Specification
1.Product installation style: Fixed type
2.Protected volume: 50m3
3.Fire extinguishing agent quantity: 1.4kg
4.Product weight: 3.4kg
5.Extinguishing fire classes: A,B,C,E
6.Discharge time: ≤9s
7.Product appearance shape: Small plate
8.Start time: 0.1s
9.Start current: ≥700mA, DC
10.Certificates of test: Type tests
Certificates of FireLess
FireLess owns several national authoritative certificates which
come from domestic most authoritative test organization-The Tianjin
Fire Research Institute of the Ministry of Public Security.
The Tianjin Fire Research Institute of the Ministry of Public
Security was established in 1965. After more than half a century of
development, it has established a professional fire research team
with strong independent innovation capability. It has gathered a
group of well-known experts at home and abroad and has a
world-class comprehensive level.
Technical parameters for Aerosol Fire Extinguishing System
| Item | Specification |
| Overall dimensions(mm) | 240( diameter)X69(height) |
| Extinguishing device weight(Kg) | 3.4 |
| Agent quantity(Kg) | 1.4 |
| Protected volume(m³) | 50 |
| Working temperature(℃) | -50℃~+95℃ |
| Safety current(mA,DC) | ≤150mA |
| Electric start-up time(s) | ≤0.1 |
| Discharge times) | ≤ 9 |
| Service life(year) | 10 |
| Trademarks | registered |
| Performance | Highly effective based on required density |
The application for special equipment use
What is the electromechanical special equipment?
Electromechanical special equipment refers to equipment that must
be pulled or driven by electric power.
Fork lifts are one of special equipment, working under different
harsh and hard environment, like high temperature weather, combined
with various factors such as vehicle routes and violations of
operations, the cases of self-ignition of fork lifts are not rare.
So what are the reasons for self-ignition of lifts?
1. Electric leakage
When the forklift is working, the safety of the entire vehicle
circuit cannot be ignored. There is a possibility of leakage after
the line is exposed or aging. Once the leakage is not only directly
harmful to people, under high temperature conditions, contact with
flammable substances may cause a fire accident.
The leakage problem of the battery forklift is even more important.
The surface connection of the battery must be kept clean. Dust and
impurities must be cleaned. Otherwise, it may cause leakage or even
a fire.
2.Grounding
In the spontaneous combustion accident caused by line faults, the
main cause is grounding.
Common faults are: broken parts between the cable and the frame and
the clamp was caused due to vibration and friction; the broken
taillights and brake light wires led to vibration and friction. The
damage of the connections causes the loose insulation. When the
vehicle is running or parked, it will automatically to be grounded
and prolong the fire, generate high temperature, causing damage to
the insulation (or foreskin) of the electrical appliances, switches
and wires, thereby increasing the jump. The fire range expands the
high temperature area and eventually causes self-ignition and fire
in contact with paint, leaking oil, and flammable materials.
3.Leaking oil
Leaking oil is the most horrible flammable material, and it is very
important to prevent fuel leakage. When the fuel in the car leaks,
the motor vehicle itself has a lot of fire sources that can ignite
the fire:
1. the high-voltage electric spark generated by the point system;
2. High temperature arc generated when the battery is externally
short-circuited;
3.The hot high temperature generated by engine exhaust or the
carbon deposited sparks.
The meanings of using fire protection
In order to avoid the economy losses and human injuries, the fire
protection is much important.
In view of its good environment adaptability , FireLess can adapt
many different environments and perform very stably. So FireLess
will be a great guard for your cared things. Besides, it is also
small in size and high fire extinguishing efficiency.
